Tower Winch Hoist

Price 450000.00 INR/ Piece

Get a Price/Quote

Tower Winch Hoist Specification

Surface
Painted

Motor Power
7.5 HP

Lifting Speed
20-22 m/min

Lifting Height
30 m

Product Type
Tower Winch Hoist

General Use
Material Lifting at Construction Site

Material
Mild Steel

Type
Electric Winch Hoist

Capacity
1000 kg

Weight (kg)
Approx. 600 kg

Computerized
No

Automatic
Yes

Control System
Push Button Pendant Control

Cooling System
Fan Cooled Motor

Method
Wire Rope Winding Mechanism

Voltage
415 V AC

Dimension (L*W*H)
2200 x 1200 x 1500 mm

Feature
Heavy Duty, High Efficiency, Durable

Color
Yellow

Tower Winch Hoist Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1 Piece Per Year

Delivery Time
1 Week

Main Domestic Market
East India

Certifications
ISO 9001: 2008

About Tower Winch Hoist

We are a widely admired manufacturer, supplier and exporter of Tower Hoist (Winch), which is made out of finest components and ultra-modern technology. The offered tower hoist is known for easy mobility, simple erection, outstanding reliability, safe and profitable attributes. Customers can avail this Tower Hoist (Winch) from us in varied specifications at affordable prices.

Features

Winch Drum: Single Drum made of superior grade casting with friction drive clutch. Winch can hold 300 ft. of wire rope.
Capacity: 1 M. Ton (1000 Kgs) Gross Weight.
Wire Rope: 12MM dia
Concrete Carrying Skip: (Silio), 10 Cft. Capacity
Trolley Speed: 20-25 Mtr./Minute
Power Unit: 15 H.P. Electric Motor 440/3/50 or 14 Aircooled Diesel Engine.
Drive: Through Chain and Fiber Rollers from the prime mover.
Bearings: Heavy duty taper roller bearings and G.M. Bushes.
Brakes: Industrial Brake Lining adjustable type.
Masts: Jig built electrically welded and fully aligned.
Tower Angle Section: 65 X 65 X 6mm (All four angles). 3.0 mts length
Chassis: Robustly constructed of heavy steel section to withstand continuous hard and rough use and mounted on 4 nos. M.S. Wheels.
Housing & Guard: Full guards on all the gears for safely of operator and moving parts.
Type: Mobile or Stationery.

Special Features: For quick erection facility mast sections are made of standard lengths for instantaneous self alignment. Automatic safety locking device with double cam action can be repeatedly applied without damaging the equipment. If required the tilting type bucket can be removed and platform can be used for lifting of other construction materials.

Heavy-Duty Performance for Tower Construction

The electric tower winch hoist is crafted from durable mild steel and boasts a lifting capacity of 1000 kg, suitable for demanding construction environments. Its heavy-duty design ensures reliable operation for material handling at building sites where safety and efficiency are paramount. The gear-driven system and electromagnetic brake deliver smooth, controlled hoisting.

Versatile Controls and Mobility

Equipped with both remote and manual operation, the winch offers flexible control options. The trolley-mounted, mobile construction allows for easy relocation and setup across different points on the site. Push button pendant controls further streamline operator tasks, making the material lifting process swift and precise.

Reliable and Efficient Motor Technology

A powerful 7.5 HP fan-cooled motor protected by an IP54 housing ensures effective operation in harsh construction environments. The system runs on 415 V AC, offering consistent lifting speeds up to 22 m/min and lifting heights of 30 m, supporting continuous workflow while maintaining durability and energy efficiency.

FAQs of Tower Winch Hoist:

Q: How is the Tower Winch Hoist installed and relocated at the construction site?

A: The winch is designed with mobile or trolley-mounted functionality, making installation straightforward. Its mobile frame allows easy repositioning by rolling to various tower levels or points on site as lifting needs change.

Q: What type of materials can be hoisted with this winch, and what is its lifting capacity?

A: This winch hoist is ideal for lifting construction materials such as steel beams, concrete blocks, and tools. Its capacity is 1000 kg, effectively supporting the movement of heavy loads up to a lifting height of 30 meters.

Q: When should the electromagnetic braking system be utilized, and how does it improve safety?

A: The electromagnetic brake operates automatically during lifting and lowering, providing instant stopping power. It enhances safety by preventing unintended descent or load shifting, especially vital during high-rise material transfer.

Q: Where can this winch hoist be used, and what types of projects benefit from its features?

A: Primarily suited for construction sites with tower structures, the winch excels in high-rise building projects, multi-story industrial installations, and any site requiring efficient vertical material transport.

Q: What is the process for controlling the winch hoist, and can it be operated remotely?

A: The winch offers dual control modes: manual via push button pendant, and remote operation. Operators choose the mode according to convenience and safety, ensuring uninterrupted lifting with easy command access.

Q: What are the benefits of the gear-driven mechanism and IP54 motor protection?

A: The gear-driven mechanism offers high efficiency and reliable power transfer, while the IP54 motor housing shields against dust and water ingress. This ensures sustained performance, low maintenance needs, and longevity in tough site conditions.

Q: How does the fan-cooled motor contribute to the winchs durability during extended use?

A: The fan-cooled motor maintains optimal operating temperatures, preventing overheating during continuous lifting tasks. This feature extends the motors lifespan and assures consistent speed and reliable power output.
